General
Brand
TP-Link
Model
TP-Link VIGI NVR2016H
Type
16 Channel NVR
Video Info
Number of Input Channel
16 Channel
Video Compression/Format
H.265+/H.265/ H.264+/H.264
Video Output (VGA)
1 Channel, Resolution: 1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz
Video Output (DVI)
No
Video Output (HDMI)
1 Channel, Resolution: 3840×2160/30Hz, 1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz
Video Output (BNC)
No
Video Recording Res.
8MP/ 5MP/ 4MP/ 3MP/ 1080p/ UXGA/ 720p/ VGA/ 4CIF/ DCIF/ 2CIF/ CIF/ QCIF
Max. Video Recording Res.
1920 x 1080
IP Video Input
16 Channel
Audio Info
Audio Compression
G.711A/ G.711U/ G.726
Audio Output Channel
1 Channel
Two way Audio
Yes
Recording & Decoding
Dual Stream Support
Unmentioned
Live View / Playback Resolution
4K
Decoding Capability
25fps: 2-ch@8MP, 4-ch@4MP, 8-ch@2MP, 30fps: 4-ch@3MP, 2-ch@5MP
Synchronous Playback
16-Channel
Network
Network Protocol
UPnP (Plug and Play), NTP (Network Timing)
Wi-Fi
No
Network Interface (RJ45)
1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
POE Interface
No
Remote Connections
The dedicated VIGI app and client enable remote monitoring, providing ease and convenience.
Auxiliary Interface
Number HDD Interface (SATA)
2 SATA
Max HDD Support (GB,TB)
Up to 10TB capacity for each disk
Max. Storage Support
20TB
eSATA
1
Serial Interface
No
USB Port
1 x Front USB 2.0 Port, 1 x Rear USB 2.0 Port
Technical Info
Display Split
1/ 4/ 6/ 8/ 9/ 16 (Multi-screen Display)
Incoming Bandwidth
80 Mbps
Outgoing Bandwidth
60 Mbps
Interoperability
ONVIF, CGI
Video Detection
Motion Detection, Video Tampering, Line-Crossing Detection, Intrusion Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned/Removal Detection, Vehicle Detection, Human Detection, Smart Frame
Compatibility
Smart Phone Supported
Android, iOS
Power Info
Power Supply
12V DC /3.3A
Approx. Power Consumption
25W
Physical Description
Color
Black
Dimensions
330 x 285 x 45mm
Weight (Kg)
1.9 Kg
Warranty
Warranty Details
2 Years
Additional Info
Feature
4K HDMI Video Output & 16MP Decoding Capacity, 16-Channel Simultaneous Playback, ONVIF Ensures Compatibility, Plug & Play, 24/7 Continuous Recording, Two-Way Audio, Remote Monitoring.
Others
Video Output Mode:HDMI/VGA Simultaneous Output, Record Mode:Manual Recording, Scheduling Recording, Motion Detection Recording, Backup Mode: Regular Backup, Video Clip Backup, Playback Function: Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off, Web Browser: Chrome (57+), Firefox (52+), Edge (91+), Interoperability: ONVIF, CGI, Audio Interface: 1, Audio In; 1, Audio Out, Anomaly Alarm: Video Loss, Offline and IP Conflict, Disk Exception, Login Exception, Fan Exception, Alarm Linkage: Recording, White Light Alarm, Buzzer, Log, Audible Alarm, Storage Temperature: -40 to 70 degree C, Storage Humidity: 10%-90% RH Non-Condensing, Certifications: CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI.
Country Of Origin
China
Made in/ Assemble
China
