General
Brand
TP-Link
Model
TP-Link VIGI NVR1004H
Type
NVR
Video Info
Number of Input Channel
04 Channel
Video Compression/Format
H.265+/ H.265/ H.264+/ H.264
Video Output (VGA)
1 Channel, Resolution: 1920 ?? 1080/60Hz, 1680?? 1050/60Hz, 1440 ?? 900/60Hz, 1280 ?? 1024/60Hz, 1280 ?? 720/60Hz
Video Output (HDMI)
1 Channel, Resolution: 3840 ??2160/30Hz, 1920 ?? 1080/60Hz, 1680?? 1050/60Hz, 1440 ?? 900/60Hz, 1280 ?? 1024/60Hz, 1280 ?? 720/60Hz
Video Recording Res.
8 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
Max. Video Recording Res.
3840 x 2160
IP Video Input
4-Channel
Audio Info
Audio Compression
G.711A/ G.711U/ G.726
Recording & Decoding
Dual Stream Support
No
Decoding Capability
2-ch @ 8MP, 4-ch @ 4MP
Synchronous Playback
4-Channel
Network
Network Protocol
UPnP (Plug and Play), NTP (Network Timing)
Wi-Fi
No
Wi-Fi Details
Not Applicable
Wi-Fi Coverage (Approximate)
Not Applicable
Network Interface (RJ45)
1 x RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
POE Interface
No
Auxiliary Interface
Number HDD Interface (SATA)
1 SATA
Max HDD Support (GB,TB)
10TB
Max. Storage Support
10TB
eSATA
No
USB Port
2 x USB 2.0
Technical Info
Display Split
1/4
Incoming Bandwidth
80 Mbps
Outgoing Bandwidth
60 Mbps
Interoperability
ONVIF, CGI
Compatibility
Smart Phone Supported
iOS, Android
Power Info
Power Supply
DC 12V/1.5A
Approx. Power Consumption
4.25 W (without disk)
Physical Description
Color
Black
Dimensions
246.2 x 148.2 x 45 mm
Weight (Kg)
0.59 kg
Package Includes
VIGI Network Video Recorder, Power Adapter, HDD Screws, Mouse, Rubber Feet, Quick Installation Guide
Warranty
Warranty Details
2 Years
Additional Info
Feature
General Alarm: Motion Detection, Video Tampering, Line-Crossing Detection, Intrusion Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned/Removal Detection, Vehicle Detection, Human Detection, Smart Frame, Anomaly Alarm: Video Loss, Offline and IP Conflict, Disk Exception, Login Exception, Alarm Linkage: Recording, White Light Alarm, Buzzer, Log, Audible Alarm, Playback Function: Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off, 4-Channel Live View and 4K HDMI Video Output, 2-ch @ 8MP/ 4-ch @ 4MP Decoding Capability, 4-Channel Synchronous Playback, 80 Mbps Incoming Bandwidth and 60 Mbps Outgoing Bandwidth, 1 SATA Interface, H.265+ Compression Technology, HDMI and VGA Simultaneous Output, Remote Monitoring
Others
Certifications: CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI, Working Temperature: NVR: -10 – 55 Degree C, Power Adapter: 0 – 40 Degree C, Working Humidity: 10%~90% RH Non-Condensing, Storage Temperature: -40 – 70 Degree C, Storage Humidity: 10%~90% RH Non-Condensing, Audio Interface: 1, Audio In; 1, Audio Out, Video Output Mode: HDMI/VGA Simultaneous Output,
Country Of Origin
China
Made in/ Assemble
China
